MOTO 530 Industrial Wood Planer Jointer Combo High-Precision Surface and Thickness Planing

Inquire Now
产品类别

Description

High – precision thickness setting: The planing thickness can be accurately adjusted by entering values into the controller, avoiding errors caused by manual adjustment of the pressure wheel and visual observation of the scale. This ensures precise thickness setting, which is beneficial for subsequent assembly processes.

Thicknessing Machine MOTO 530 MOTO 630
Max. working width mm 530 630
Cutterblock diameter mm 120 120
Max. cutting depth mm 8 8
Feed speed MT/1′ 5-20 5-20
Max. working height mm 300 300
Number of knives 　p- mm 4p-30*530*3 4-30*630*3
Cutterblock rotation speed g/1′ 4800 4800
3-phase motor power HP (KW) 7,5 (5,5KW) 7,5 (5,5KW)
Power of the motorgear for rise/fall HP (KW) 0,5 (0,33KW) 0,5 (0,33KW)
Feeder motor power HP (KW) 1,0 (0,75KW) 1,0 (0,75KW)
Work table dimensions mm 1050 x 532 1050 x 632
Min. working lenght mm 280 280
Net weight kg 810 875
Sound power level at operator’s site db 82,2 82,2
Standard Accessories MOTO 530 MOTO 630
Knife-setting device ● ●
4 pcs planing knives ● ●
Motorized thicknesing table lifting ● ●
Sectioned feeding roller ○ ●
Optional accessories MOTO 530 MOTO 630
1 Table roller
2 Table rollers Standard
Motor HP (KW) 10,0(7.5KW) 10,0(7.5KW)
Control electroinstallations and quota volocita MT/1′ * Standard
Feeding rollers rubber output * *
Sectioned feeding roller * Standard
