MD400

Automatic Feeding Precision Wood Cutting Saw Machines Horizontal Thin Band Sawmills

Inquire Now
产品类别

Description

  1. Human oriented micro computer operator interfaces, for easy and convenience operating.
  2. Sawing width is controlled by the combine use of rotary high precise encoder and rigid ball screwod, to provide higher
    accuracy.
  3. Use asisted reefed system, save time, save labor and free from worry.
  4. PLC intergrated controlsystem, save and reliable. Bandsaw Resaw Band Sawmill Saw Mill.
  5.  Hydraulic saw blade tension auto-compensation system ensure the saw blade is always staying a bes tension status and provides a longer service life.
Product type MD400 MD500 MD650 MD800 MD1000 MD1300
Maximum machining width 400mm 500mm 650mm 800mm 1000mm 1300mm
Saw blade to table distance 3-220m 3-220m 3-200m 3-200m 3-200m 3-120m
Saw wheel diameter 700mm 700mm 700mm 700mm 700mm 700mm
Feed speed(Frequency Control) 0-18m/min 0-18m/min 0-18m/min 0-18m/min 0-18m/min 0-18m/min
Conveyor motor 1.1kw 1.1kw 1.1kw 1.1kw 1.5kw 1.5kw
Lifting motor 0.37kw 0.37kw 0.37kw 0.37kw 0.37kw 0.37kw
Saw wheel motor power: 15kw 18.5kw 18.5kw 22kw 22kw 30kw
Total power 17.22kw 21.12kw 21.12kw 21.12kw 21.12kw 21.12kw
Machine size(mm) 2150*2150*1850 2250*2300*1850 2450*2300*1950 2600*2300*1950 3000*2300*1950 3300*2300*1950
Machine weight 1800kg 1900kg 2100kg 2300kg 2500kg 2750kg
