Applicable scope: solid wood composite floor, reinforced composite floor, board furniture,environmental protection sound-absorbing board, wooden packing box, integrated wood, picture frame, bed row framework/board once saw into many equal or different specifications of material processing, and can be cut in the material slot. Precision saw shaft to ensure that the saw out of the plate finish and straightness more accurate.
| Technical Parameter | MJ1300-X3 | MJ1300-XD3 | MJ1300-XD4 |
| Spindle speed(r/min) | 2600 | 2600 | 2600 |
| Saw blade diameter(mm) | 205 | 255 | 255 |
| Spindle of diameter(mm) | 74 | 85 | 90 |
| Width of processed material(mm) | Max1220,Min200 | Max1220,Min200 | Max1220,Min200 |
| Thickness of processed material(mm) | Max30,Min5 | Max45,Min5 | Max50,Min5 |
| Minimum processed length(mm) | 550 | 600 | 600 |
| Power of spindle motor(kw) | 22 | 37 | 45 |
| Feeding motor(kw) | 1.5 | 2.2 | 3 |
| Feeding speed(m/min) | 0-12 | 0-12 | 0-12 |
| Weight(kg) | 1460 | 1700 | 2400 |
| outsize(mm) | 2050*1800*1600 | 2400*1800*1600 | 3000*1900*1700 |
