Square wood multi-blade rip saw is mainly used for sawing square wood into multi-standard square pieces, with advantage of large processing diameter, smooth feeding, no burning saw blade, small sawing road, high safety, smooth sawing surface and yield rate . It is the most ideal woodworking machinery for processing finger joints, joinery boards, packaging boards, etc. It can be changed according to the thickness of the sheet you want to saw, and the different sheets can be sawed, and the length and length of materials can be processed. Poplar, pine, eucalyptus, fir, green steel and other hardwoods.
| Model | MJ200C | MJ200D |
| Working length | 200-4000mm | 80-4000mm |
| Working width | 10-200mm | 5-200mm |
| Working thickness | 10-80mm | 5-60mm |
| Feed motor power | 1.1kW (stepless) | 1.1kw(stepless) |
| Feed speed | 4-20m/min | 4-20m/min |
| Spindle motor power | 11kW | 11kW |
| Spindle speed | 3600r/min | 3600r/min |
| Max blade diameter | Φ230mm | Φ230mm |
| Extraction outlet size | Φ125mm | Φ125mm |
| Spindle diameter | Φ35mm | Φ35mm |
| Lifting motor power | 0.37kW | 0.37kW |
| Beam lift motor power | 0.37kW | 0.37kW |
| Total Power | 12.84kW | 12.84kW |
| Air Pressure | 0.6Mpa | 0.6mpa |
| Overall size | 1750*850*1550mm | 1750*850*1550mm |
| Weight | 900kg | 900kg |
