描述
1. The operation is light and labor-saving, the driving stroke is large, and the cutting width is large;
2. Equipped with stable and lightweight towing frame, running smoothly;
3. The setting of the mobile table and the main saw blade can be adjusted by 45 degrees,which expands the scope of use of the saw machine.
| Technical Parameter | |||
| Sliding table length * width | 3200*390mm | Tilting saw blade | 45°-90° |
| Max cutting length | 3200mm | Main motor | 5.5kw |
| Max cutting width | 1300mm | Scoring saw blade diameter | 120mm |
| Main saw blade diameter | 300mm (250-400mm) | Scoring saw spindle speed | 7000-8000rpm |
| Height of cut at 90° | 75mm | Scoring spindel diameter | 20mm |
| Main saw spindle speed | 4000-6000rpm | Scoring motor | 1.1kw |
| Main spindle diameter | 30mm | Overall dimensions | 3350*1100*1300mm |
