Mainly used for parts of the surface pattern milling, relief and other processing, can also be used for part shape curve milling, internal imitation milling and other processing.
This type of heavy load, can be mounted a variety of specifications of the saw blade, cutter, speed more variety of options for furniture, decorative wood line, straight, copy the milling.
| Model | MX5117A | MX5117B |
| Platform size | 2700*700mm | 2700*700mm |
| Spindle diameter | 35mm | 35mm |
| Spindle speed | 6000/8000/10000r/min | 6000/8000/10000r/min |
| Maximum machining thickness | 70mm | 70mm |
| Maximum spindle lifting height | 200mm | 200mm |
| Spindle power | 4KW | 5.5KW |
| Machine size | 2700*700*1170mm | 2700*700*1170mm |
| Machine weight | 600 KG | 600 KG |
